Single layer air-cooled wire tube condenser
Bundy tube | Outer Diameter: Ø4.76mm, Ø6mm, Ø6.35mm, Ø8mm, Ø9.52mm |
Wire | Outer Diameter: Ø1.0mm---Ø1.6mm |
Coating corrosion resistant | Cathodic electrophoresis coating: ≥96 hour |
Multiple layers air-cooled wire tube condenser
Bundy tube | Outer Diameter: Ø4.76mm, Ø6mm, Ø6.35mm, Ø8mm, Ø9.52mm |
Wire | Outer Diameter: Ø1.0mm---Ø1.6mm |
Bracket | Steel plate, Thickness: 0.6-2.0mm |
Coating corrosion resistant | Cathodic electrophoresis coating: ≥96 hour Cathodic electrophoresis coating add powder painting: ≥240 hour |
Wire tube condenser for water dispenser
Bundy tube | Outer Diameter: Ø4.76mm, Ø6mm, Ø6.35mm, Ø8mm, Ø9.52mm |
Wire | Outer Diameter: Ø1.0mm---Ø1.6mm |
Coating corrosion resistant | Cathodic electrophoresis coating: ≥96 hour |
Wire tube condenser for semi-conductor refrigeration
Bundy tube | Outer Diameter: Ø4.76mm, Ø6mm, Ø6.35mm, Ø8mm, Ø9.52mm |
Wire | Outer Diameter: Ø1.0mm---Ø1.6mm |
Coating corrosion resistant | Cathodic electrophoresis coating: ≥96 hour |
semi-conductor refrigeration chip | Length 39.88mm, Width 39.88, Height 3.81mm Voltage 12V, Vmax 15.4V, Imax 6A, Qcmax 92W |
